8x5 Off Road Box Trailer
Our popular 8x5 box trailer, your best mate on and off road
Quick Specs
Box Size
8 x 5
Side Height
500mm
Cage Height
500mm
Price
$4450
Prev
Next
ONLY $4450 Standard | $4750 Independent INC GST!
CALL NOW TO PLACE YOUR ORDER.
* ON ROAD COSTS ADDITIONAL, CONTACT US FOR DETAILS.
8×5 OFF ROAD BOX TRAILER FEATURES
General
| Build Quality | Heavy duty |
| Galvanised | Yes (hot dipped) |
| Rails | Heavy duty tie down, all sides |
| Wheels | 15 inch white rims, Ford stud stud pattern |
| Tyres | New steel belted tubeless radial |
| Floor | 2.5mm checker plate |
| Axles | 50mm solid square |
| Suspension | 7 leaf springs(STD), Dual shick coil (Independent) |
| Brakes | Electric drum brakes both axles |
| Chassis | 100x50x4mm box construction |
Optional Extras
| ARK XO 500 Heavy Duty Jockey Wheel | $380 inc GST |
| ARK XO 750 Off Road Heavy Duty Jockey Wheel | $450 inc GST |
| DO35 Cruise Master hitch (Independent Suspension) | $520 inc GST |
Availability (call to confirm)
| Newcastle | 1300 422 922 |
| Perth | 0491 133 191 |
| Sunshine Coast | 07 5453 7960 |
| Brisbane | 07 2106 0677 |
| Delivery | Yes, Australia-wide |
| Phone Order | Yes (see above) |
Size
| Cage Height | 500 mm (front + rear swing gates) |
| Box Size | 8 x 5 (2.44m x 1.52m) |
| Box Height | 500 mm |
| Tare Weight | 760 kg |
| GVM Capacity | 1,500 kg Standard | 1800kg Independent |
| Drawbar | 1700mm, 100x50x5mm box construction |
Electrics
| LED Lights | Yes (Australian Roads Compliant) |
| Plug Type | 7 Pin Flat (AR Compliant) |
Inclusions
| Compliance Plate | Yes (included) |
| VIN | Yes (included) |
| Spare Wheel | Yes (included) |
| Jockey Wheel | Yes (included) – swing up model |
| Safety | Hammer lock attached safety chains |
| Warranty | 12 months parts, 6 year structural |
